Features

  • Lifetime Guarantee on Hook and Hook Plate
  • Rudco Roll-Offs feature tube main rails with solid bullnose
  • All containers are primed and painted in one of ten standard colors
  • Formed front corner posts for added strength
  • Non-Sagging Door is designed to rest on floor of container
  • Large “V” notches in each vertical support column prevents moisture retention
  • Barn Style Rear Gates
Download Brochure

Product Specifications

Rudco Storage Containers Dimensions
A
B
  • 25 YD
    (A ) DECK LENGTH
    168”
    (B) OVERALL LENGTH
    179”
    APPROXIMATE WEIGHT
    3,500 LBS.
  • 29 YD
    (A ) DECK LENGTH
    192”
    (B) OVERALL LENGTH
    203”
    APPROXIMATE WEIGHT
    4,000 LBS.
  • 34 YD
    (A ) DECK LENGTH
    216”
    (B) OVERALL LENGTH
    227”
    APPROXIMATE WEIGHT
    4,550 LBS.
  • 40 YD
    (A ) DECK LENGTH
    264”
    (B) OVERALL LENGTH
    275”
    APPROXIMATE WEIGHT
    5,700 LBS.

Color Selections

White
P03-077 / AAW0430
Beige
P03-080 / AAD0321
Light Blue
P03-083 / AAL0713
Dark Blue
P03-066 / AAL0708
Red
P03-075 / AAL0787
Burgundy
P03-085 / AAW0616
Dark Green
P03-064 / AAG0864
Maritime Teal
P03-084 / AAL0868
Yellow
P03-079 / AAL1014
Orange
P03-079 / AAL0306
Dark Gray
P03-076 / AAW1047
Dark Brown
P03-067 / AAG0228
Black
P03-078 / AAL1033
Speciality colors are available upon request. Colors shown are an approximate match.

Technical Details

Standard Deck
  • 3/16” PL. Floor 2 Piece
  • 3” Structural Channel on 20” Centers
  • 3/16” PL. Gussets on every other Cross Member
  • 2” x 6” x 3/16” Tube One Piece Main Rails
  • 4” Diameter x 6” Long Bullnose Rollers W/ 1-1/2″ Greasable Pin
  • 1” Cable Hook PL WIth 1 1’4” Solid Cable Hook
  • (4) 8” Diameter x 10” Long Heavy Duty Wheels W/ 1-1/4” Diameter Axles
Front and Sides
  • 12 Ga. Sheet
  • 12 Ga. Front Sheet
  • 3” x 4” x 11 Ga. Top Tube
Rear Corner Post
  • 3” x 4” x 11 Ga. Tube
Roof
  • 4” Pitch with 12 Ga. sheets and 3” channel support
Rear Door
  • Barn Style Rear Door
  • 11 Ga. Sheet w/ 3” x 4” x 11 Ga. Tube Frame and 3/8” Safety Chain
  • Hinges ½” x 7” x 9” and ½” x 3” x 3” Plates with 2” OD Mechanical Tube Bushings with Grease Fittings and one 3/16” Cold Rolled Pin
  • Non-Sagging Door is designed to rest on the floor of the container
Door Lock
  • Cam action type door lock, 1 -1/4” Cams on 1-1/4” Dia. solid bar to 3/8” Locking Plates. Swing Handle is securely welded to a cam assembly rod for easy opening and closing operations. Handle is secured by 1/2” x 2” bar stock with safety chain.
Top
  • 4” Pitch Roof With 11 Ga. Steel 3” Channel Supports

NOTE: Recycle Containers can be stacked 5 or 6 per load.This saves freight cost per container.
However, when stacking and unstacking, doors have to be removed and re-hung, and the containers may be scratched or dented.
We cannot be responsible for this happening since it is unavoidable when stacking containers.
